TENSOR SERIES PORTABLE PA
EXAMPLE 1 - Daisy chained
If additional cabinets are required in the signal chain, simply connect the Mix Out of the primary cabinet to the Input of the
Secondary cabinet.
© 2021 HH Electronics Ltd
PRIMARY CABINET
INPUT 1 INPUT 2
0 0
LINE MIC LINE MIC
GAIN GAIN
INPUT 1 INPUT 2
SECONDARY CABINET
INPUT 1 INPUT 2
0 0
LINE MIC LINE MIC
GAIN GAIN
INPUT 1 INPUT 2
