TENSOR SERIES PORTABLE PA
INTRODUCTION
The HH Tensor Series Engineered in the UK to deliver power, performance and reliability.
The Class-D Bi-Amplifier delivers impressive output performance in an ultra-lightweight enclosure.
On-board DSP provides audio enhancements depending on audio source and includes overload protection. Four acoustically tuned
audio modes are provided for flexibility for use in a multitude of situations.
Whether that's for a DJ, live band, monitoring or announcements, the Tensor has it covered with the press of a button.
High-quality integrated two channel mixer gives multiple options for input sources. Each input has HH designed low-noise preamps
with combo XLR/TRS connectors for both Line Level and microphone gain levels.
All this contained in a multi-angle enclosure that includes three moulded carry handles, pole mount socket and four M8 suspension
points.
The HH Tensor – delivering performance and reliability.
GETTING STARTED
This manual contains important information regarding correct and safe operation of your Tensor system. Please read it thoroughly in
order to get the best performance and reliability from your HH product.
VOLTAGE SELECT SWITCH
Although every effort has been made to select the correct voltage for the region of use, please
check before powering up for the first time. Damage could occur if the voltage is incorrectly
set. If necessary, use a suitable tool to slide the Voltage Selector Switch to the required setting.
POWER CYCLE
Many products have large transient surges at turn on and off which can cause damage to your
speakers. Following the sequence below for power-up and the reverse for power down will prevent
this from occurring.
1
POWER
POWER SWITCH - OFF
4
INPUT 1
CONNECT INPUT SIGNAL
© 2021 HH Electronics Ltd
2
CONNECT POWER
5
POWER
POWER SWITCH - ON
Designed and Engineered in the UK by HH Electronics LTD.
LIVE SOUND
110-120V setting
110-120V~
VOLTAGE SELECT
220-240V setting
110-120V~
VOLTAGE SELECT
3
MAIN
LIMIT
VOLUME
SET VOLUME TO MINIMUM
6
MAIN
LIMIT
VOLUME
SET VOLUME AS REQUIRED
EN
220-240V~
220-240V~
5
