TENSOR SERIES PORTABLE PA
SPECIFICATION: TRE-1001
Speaker
Crossover Frequency
Features
AC Power Consumption
Enclosure
Unit dimensions (HWD)
Carton dimensions (HWD)
In the interest of continued development, HH Electronics reserves the right to amend product specification without prior notification.
300
385
© 2021 HH Electronics Ltd
System type
2 way active 10" loudspeaker, Bass reflex
Power Rating
1400W Peak, 700W Continuous
Frequency response
48Hz-20KHz
Max SPL (1M) (Peak)
129 dB SPL
LF Driver
10" HH designed professional low mid driver featuring imported glass reinforced cone
HF Driver
1" Compression Driver
Coverage
90°H X 60°V
2.5KHz
Input Connectors
2x Balanced Combi XLR/1/4" Jack connectors
Output Connectors
1x Balanced XLR Mix Output
Indicators
Power, Clip Indicator, EQ Mode, Front illuminated logo
EQ
User selectable performance presets for Music, Live, Monitor, Vocal
DSP
Crossover, EQ, Dual Band Limiters, Phase and Time Optimisation
Comprehensive protection and clip free limiting + clip indicator
Protection
2x channel gain, Master Volume, logo on/off, Ground Lift, EQ Mode
Controls
AC Power
User Switcheable 100-120V~ or 220-240V~ 50/60HZ
300W Typical
Cabinet
Robust polypropylene cabinet with two handles and monitor angle
Finish
Black
Grille
Heavy Gauge powder-coated steel, Black with acoustic foam backing
Other
35mm Distance Pole Socket
Flying points
4 x M8 Mounting Points
530 x 300 x 310 mm
20.9" x 11.8" x 12.2"
Unit weight
11.6Kg, 25.6 lbs
61.5 x 390 x 385 mm
2.4" x 15.4" x 15.2" (Shipping Volume 0.01 M3)
Packed weight
13.6Kg, 30 lbs
EAN13 Code
5060109457551
For polar plots, EASE modelling files, 2D and 3D drawings files, please check www.hhelectronics.com
1 Measured in Full space (4π) conditions
2 Calculated maximum SPL based on rated power handling
3 AES standard, pink noise with 6 dB crest factor, free air.
530
Designed and Engineered in the UK by HH Electronics LTD.
EN
LIVE SOUND
60° MONITOR ANGLE
14
