3.3 POWER CONNECTIONS

• To avoid the switchboard from overheating (which could cause a fire), check that the ter-
minal blocks are securely fastened. Loose terminal blocks will cancel the warranty.
• Any unsuitable electrical connection will make the warranty null and void.
• The power cable must be insulated and protected against chafing and damage.
• Use the cable gland to thread the power cable through the device.

3.3.1 ELECTRICAL CONNECTIONS

Disconnect electricity and ground the pump before beginning electrical work.
1. Unscrew the 4 screws to open the connection box.
2. Disconnect and remove factory test wires from the terminal block.
3. Run the power cable through the gland and connect wires.
4. Close the electrical connection box, making sure the gasket is in place, and tighten the 4 screws.
Blue
White
Black
L N
Red
V1
Black
U1
U
Installation and general maintenance manual
White
W1
Yellow/Green
V W
400V Y
- POOL PUMPS
Yellow/Green
Single- phase - 230Vac-50Hz
L1
N
S
M C
H
U
V
W
N
U V W
1 1 1
M3
Three-phase - 400Vac-50Hz
