| TECHNICAL SPECIFICATIONS

MAIN FEATURES
|
Integrated Amplifier:
125watt @ 8Ω per channel Class A/B
Mosfet
|
Ethernet LAN and Wi-Fi:
802.11b/g via RJ45 10/100Mbps socket
(PCM24/192 and DSD64)
|
UPnP and DLNA supported
|
Phono Stage:
MM (+34dB, 47kΩ)
MC (+49dB, 470Ω)
|
THD (Total Harmonic Distortion):
0,005% @ 5W
0,1% @ 0,1 to 50W (20Hz - 20kHz)
|
Damping Factor:
>100
|
Output impedance:
50Ω
|
Signal-to-Noise ratio (S/N):
> 100dB line and digital inputs
> 80dB phono input
|
Booster:
3 options (Booster 1, Booster 2, Off)
|
DAC:
IS-1000 LINE - BurrBrown PCM1796
IS-1000 DELUXE - BurrBrown PCM1792A
NETWORK
COAX
TOS-Link
USB-A
POWER
|
Power supply:
100-120V or 220-240V, 50/60Hz
|
Power consumption:
30 - 400W max
|
Fuse:
220/240V 3,15A F/T
100/120V 6,3A F/T
ANALOGUE OUTPUTS
1x
RCA variable (up to +9,5dB, 4Vrms max)
1x
RCA fixed (0dB, 1.4Vrms)
ANALOGUE INPUTS
1x
XLR balanced
1x
RCA Line / Phono MM/MC*
1x
RCA Line / AV
*The phono input is not available on
IS-1000 LINE
RESOLUTION
PCM 24/192
3
DSD64
