Instructions for installation
No. Name
Corner posts
7 Corner post A
8 Corner post E
9 Corner post EP
10 Corner post F
11 Corner post C
12 Corner post D
13 Corner post G
14 Corner post H
Roof elements
15 Roof element
16 Roof element
17 Roof frame
17 Roof frame
17 Roof frame
17 Roof frame
18 Roof rim
18 Roof rim
18 Roof rim
18 Roof rim
18 Roof rim
Corner covers
19 Inner roof corner trims
19 Inner roof corner trims
19 Inner roof corner trims
20 Inner corner trim
21 Outer corner covers
22 Outer corner covers
23 Outer corner covers
24 Outer corner covers
Pcs Dimensions
(mm)
S1616CV
1 1949x93x84
1 1949x93x84
1 1836x77x76
2 1836x77x44
1 1597x995x64
1 1597x602x64
1 1567x45x32
1 1521x45x32
1 459x45x32
1 541x45x32
2 1634x95x15
1 1383x95x15
2 657x95x15
1 1447x18x15
1 1428x18x15
2 544x18x15
3 1025x20x20
2 1900x77x15
1 1900x64x15
1 1900x64x15
p. 6/10
Pcs Dimensions
(mm)
S2020CV
1 1949x85x45
1 1949x87x81
1 1949x87x81
1 1949x95x69
1 1836x77x76
1 1836x77x44
1 2022x1027x64
1 2022x968x75
1 1992x45x32
1 1864x45x32
1 966x45x32
1 2060x95x15
1 2033x95x15
1 1376x95x15
1 1088x95x15
1 1059x95x15
1 1868x18x15
1 1848x18x15
2 966x18x15
2 1025x20x20
2 1900x77x15
1 1900x64x15
1 1900x40x15
