Instructions for installation

1.2. Maintenance and cleaning

● The sauna should be cleaned with a damp cloth. Only use warm water – no
cleaning products.
● We recommend heating the cabin once a month if the sauna is not used for
a long time.
Pitch pockets are not grounds for return, since they can always appear in
spruce wood and the depth at which they lie cannot be detected during
the sorting-out process.
If these are just under the surface, heat can cause them to soften and
"bleed".
The leaking pitch can be removed with a rag soaked in acetone. If only
droplets of pitch occur, allow these to harden and then carefully scrape
them off with a knife.

1.3. Disposal

● Dispose of packaging materials in accordance with the applicable
waste disposal regulations.
● Used devices contain reusable materials as well as hazardous sub-
stances. Therefore, do not dispose of your used device with household
waste, but do so in accordance with the locally applicable regulations.

1.4. Parts list for Corner S1616CV and Corner Large S2020CV

Illustrations for parts list on page 11 (following the last language of the instructions)
No. Name
Base frame
1 Base frame
2 Base frame
3 Base frame ventilation aperture
Wall elements
4 Wall elements 510
4 Wall elements 935
5 Electrical element 510
5 Electrical element 935
6 Ventilation element 510
6 Ventilation element 935
Pcs Dimensions
(mm)
S1616CV
2 587x68x43
1 1567x68x43
1 1567x68x43
2 1900x510x75
2 1900x935x75
1 1900x510x75
1 1900x510x75
p. 5/10
Pcs Dimensions
(mm)
S2020CV
1 1012x68x43
1 1992x68x43
1 1947x68x43
3 1900x935x75
1 1900x935x75
1 1900x935x75
EN
