C o n t r o l s
A
B u t t o n
F u n c t i o n
A
Turns the lighting system on and off at maximum intensity.
Turns the lighting system on and off in Courtesy Light mode.
B
Turns the Motor off.
Press and hold for approximately 5 seconds to Lock / Unlock the
Keyboard, for example in order to clean the surface.
C
Turns the Motor on at Speed one.
D
Turns the Motor on at Speed two.
E
Turns the Motor on at Speed three.
F
Activates/Deactivates i n t e n s i v e speed from any other speed, including
motor off. This speed is set to operate for 10 minutes, after which
the system returns to the speed that was set before. Suitable to deal
with maximum levels of cooking fumes. Can also be deactivated by
pressing button B.
Press and hold the button for approximately 5 seconds, with all the
loads turned off (Motor and Lights), to turn the Activated Charcoal
Filter alarm on/off.
G
2 4 H f u n c t i o n
Turns the motor On/Off at speed one and allows recirculation for 10
minutes every hour. It cannot be activated if the I n t e n s i v e or D e l a y
functions are in use.
When the filters alarm is triggered, the alarm can be reset by pressing
and holding this button for approximately 5 seconds.
These indications are only visible when the motor is turned off.
H
D e l a y f u n c t i o n
Activates/Deactivates automatic switch-off with a 30' delay. Suitable to
complete elimination of residual odours. Can be activated from any po-
sition. It cannot be activated if the I n t e n s i v e or 2 4 H functions are in use.
Press and hold the button for approximately 5 seconds, with all the
loads turned off (Motor and Lights), to turn the Remote control on/off.
R
Remote control receiver.
L i g h t i n g
Warning: This appliance is fitted with a white LED lamp
classed as 1M according to EN 60825-1: 1994 + A1:2002
+ A2:2001 standards; maximum optical power emitted
@439nm: 7µW. Do not look directly at the light through
optical devices (binoculars, magnifying glasses...).
• For replacement contact technical support. ("To purchase
contact technical support").
4
B
C
D
E
F
G
L e d
On/Off.
On/Off.
The buttons turn light up one at a time in cycle.
On/Off.
On/Off.
On/Off.
Flashes once a second.
B u t t o n B (Flashes twice)-Alarm Activated.
B u t t o n B (Flashes once)-Alarm Deactivated.
On/Off.
B flashes three times.
When the procedure terminates, the indication shown
previously turns off:
Button G flashes, indicating the need to wash the metal
grease filters. The alarm is triggered after the Hood has
been in operation for 100 working hours.
Button G flashes, indicating the need to change the
activated charcoal filters, and also to wash the metal
grease filters. The alarm is triggered after the Hood has
been in operation for 200 working hours.
On/Off.
B u t t o n B (Flashes twice)-Remote control Activated.
B u t t o n B (Flashes once)-Remote control Deactivated.
H
R
