We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-
8669).
41
4
31
19
9
9
13
21 Φ47*40*M8 1PC
18
21
A
40
A
STEP 6:
Insert the Meter (No. 41) onto the tab on the Handlebar
(No. 4).
STEP 7:
Take out the Knob (No. 21) from the manual bag.
Attach the Fixed Iron Sheet (No. 19) to the Seat
Connecting Tube (No. 31), adjust the Seat (No. 18) to
your desired position, then tighten and secure with the
Knob (No. 21).
STEP 8:
Attach the Left & Right Pedals (No. 13 & No. 40) to
the Pedal Connecting Tube (No. 9) and tighten Left &
Right Pedals (No. 13 & No. 40) clockwise with Spanner
(No. A).
