General description

1. Burst of steam regulator
2. Steam button
3. Spray button
4. Handle
5. Power cord
6. Water inlet
7. Thermostat
8. Light indicator
9. Spray nozzle
10. Self cleaning button
11. Water reservoir
12. Base
13. Soleplate

Technical data

- power: 1800W
- mains voltage: 230V ~ 50Hz
OPERATION GUIDE
Before using the iron for the first time you should remove (unstick) the protection layer from
the soleplate (13) and unwind entirely the power cord (5). At the beginning of the exploitation
a harmless smell can come out. This fact does not influence the working of the device and
goes by quite quickly.
Before connecting the iron to the power supply you should put it on the base (12), set the
thermostat to MIN and burst of steam regulator to
After the device is connected to the power supply and desired temperature is set the light
indicator starts to glow. The indicator light goes out when the appliance reaches the desired
temperature.
The ironing temperature should be adequate for the type of fabric. If the fabric type is
unknown ironing should begin at the lowest possible temperature that is gradually increased
until satisfying effects are reached.
DRY IRON
Put the iron on the base (12), set the burst of steam regulator to
Before connecting the iron to the power supply or switching it ofF the thermostat (7) should
be always set to MIN position.
STEAM IRON
Steam iron function can be only used with high temperature settings. The highest temperature
is marked as MAX at the thermostat. The amount of steam is set with burst of steam
regulator (1).
Steam off
For additional burst of steam use steam button (2).
CAUTION. Steam is hot. There is a danger of scald. Soleplate heats up slowly but it needs
more time for cooling down. Therefore it should not be touched.
4
All manuals and user guides at all-guides.com
Instruction manual
R
1
6
9
Low steam
Steam iron DA24C
2
3
7
10
position (steam off).
position.
High steam
4
5
8
11
12
13
