7.12
Camera mounting
(if provided)
The camera version is only avail-
able in certain countries.
Camera mounting
1 Drill the pre-cut adhesive with a
screwdriver
2 Position the camera mounting plate
near the holes in the front panel of the
frame
3 Pass the camera's usb cable through
the hole
4 Mount the camera already attached to
the bracket using the expansion rivets
5 Connect the USB cable to the Digital
ADAS CPU
