5. Description of the equipment

5.1

Main components

Main components
a Mobile support structure
65" Digital Target
b
c Laser rangefinder DLM-01
Mirror for laser calibration
d
e Metric bar with magnetic strip
f Digital ADAS CPU with keyboard
g Structure vertical movement remote
control
Camera (if any)
h
f
g
5.2

Intended use

The equipment covered by this manual has been
designed for a simple and reliable calibration
of driver assistance systems, such as cameras
and radar. Digital ADAS 2.0 must be used
in conjunction with a scantool produced by
MAHLE Aftermarket Italy S.p.A. (see manual of
the scantool instrument).
h b
d
c e
a
