Sentiotec SCALA Large Montageanleitung Seite 10

Instructions for installation
No. of
Name
items
Terrace
6 Base frame (impregnated)
32 Terrace floorboards
2 Cover strip
2 Screen element
2 Roof supports
Accessories
2 Ventilation slide 620P
2 Ventilation grille
2 Headrest 520S
1 Lamp protective grille 920S
1 Lamp without bulb
2 Polymer adhesive (290 ml)
12 Stainless steel ventilation grille
2 Metal angle
146 Iron pins
2 Roofing felt
1 Assembly material set
1 Assembly instructions
p. 10/14
Dimensions
mm
2090x95x40
825x120x25
825x95x25
1970x780x60
2550x70x70
215x170x20
250x250x30
430x250x70
60x60x3
120x12x2
