EN
Technical data
Adjustable control range
Factory pre-setting
Temperature range for thermal disinfection
Max. permissible operating temperature
Nominal pressure
Nominal sizes
Type
Noise protection
+
Flow diagrams
8 /32 – K410014100002-00 / 12.2021 – © www.kemper-olpe.de
Annex
50 °C - 65 °C
58 °C
≥ 70 °C
90 °C
PN 16
DN 15 | DN 20 | DN 25
Figur 141 - male thread with flat gasket,
alternatively incl. or excl. screw coupling
Figur 143 - with female thread
The pressure difference Δp across the regulating
valve should always be above ≤ 400 mbar.
Accessories
1 Drain Valve
2 Dial Thermometer or
Temperature Sensor Pt 1000
