C18B, C46B, D18B, D42B, D46B
6.2 Integrating free-standing wine coolers
The wine cooler can be integrated either under a countertop or between other cab-
inets (fig. 3, page 4).
Observe the following, when integrating the wine cooler:
• Observe the installation dimensions (fig. 4, page 4).
• Ensure the door will open and close properly in the chosen location.
• Waste heat produced by the wine cooler must be extracted via ventilation open-
ings on the rear and at both sides.
6.3 Mounting the door handle
➤ Mount the handle as shown (fig. 5, page 5 and fig. 6, page 5).
6.4 Adjusting the feet
➤ Make sure the wine cooler is level by adjusting the feet (fig. 7, page 6).
6.5 Adjusting the ventilation grille
➤ Adjust the height of the ventilation grille (fig. 7, page 6).
6.6 Changing the door hinge
You can change the hinge of the door, so that it opens to the left rather than the right.
1. Proceed as shown to change the door hinge (fig. 9, page 7 to fig. d, page 9).
2. Reverse the door handle (fig. e, page 10 and fig. f, page 10).
6.7 Connecting the wine cooler
Observe the following when connecting the wine cooler:
• Leave the wine cooler to stand upright for about 2 hours after transporting,
before you connect it to the power supply. Otherwise this could cause faults in
the cooling system.
• Connect the wine cooler to a circuit that is protected with 15 A.
• Have the socket and power circuit checked by a qualified electrician to ensure
that the socket is earthed correctly. Do not use an extension cable or a multiple
power socket.
EN
Installation
23
