SPECIFICATIONS

Model
ECO15
ECO20
ECO25
ASSEMBLY
FITTING THE CASTORS
WARNING THIS APPLIANCE MUST BE EARTHED
WARNING The radiator must only be operated with the wheels and castors fitted and in the upright position.
The castors must be fitted to the control panel and on the bracket between the last and second last fin on the opposite end, as
shown in Fig.1.
To fit the castors, turn the radiator upside down on a carpet or other soft surface to avoid damage.
WARNING : THE RADIATOR IS HEAVY – ENSURE THAT IT IS SUPPORTED TO PREVENT IT FROM TOPPLING. Ask a second
person to help with this if necessary.
To fit the castors, position the castor plates (A) in position and secure using the wing bolts (B). There are guides to ensure the
correct positioning and orientation of the caster plate.
Return the radiator to the correct orientation so it rests on the castors. The product is now ready for use.
Fig. 1
Description
7 fin, thermostat, three heat settings & Neon
9 fin, thermostat, three heat settings & Neon
11 fin, thermostat, three heat settings & Neon
FR DE EN NL PL SV
Power (W)
1500
2000
2500
