2.
Close the lock lever.
3.
Attach the dust nozzle to the trimmer base, and
then tighten the thumb screw.
► Fig.22: 1. Dust nozzle 2. Thumb screw
► Fig.23
To remove the base, follow the installation procedure in reverse.
When using the tool with the trim-
CAUTION:
mer base, be sure to install the dust nozzle on the
trimmer base.
NOTE: In some countries, the dust nozzle may not be
included in the tool package as standard accessory.
Installing or removing the tilt base
Optional accessory
1.
Open the lock lever of the tilt base, then insert the
tool into the tilt base aligning the groove on the tool with
the protrusion on the tilt base.
► Fig.24: 1. Lock lever
2.
Close the lock lever.
To remove the base, follow the installation procedure in reverse.
Installing or removing the offset base
Optional accessory
1.
Press the shaft lock, then loosen the collet nut.
► Fig.25: 1. Collet nut 2. Shaft lock 3. Wrench
2.
Remove the collet nut and the collet cone.
► Fig.26: 1. Collet nut 2. Collet cone
3.
Install the pulley on the tool by pressing the shaft
lock and tightening the pulley with the wrench.
► Fig.27: 1. Wrench 2. Pulley 3. Shaft lock
4.
Loosen the screws on the base plate, and then
remove the base plate.
► Fig.28: 1. Base plate
5.
Open the lock lever of the offset base, then insert
the tool into the offset base.
► Fig.29: 1. Lock lever
6.
Mount the belt to the pulley by rotating the belt manually.
► Fig.30: 1. Pulley 2. Belt
7.
Close the lock lever.
► Fig.31: 1. Lock lever
8.
Attach the base plate by tightening the screws.
► Fig.32: 1. Base plate
9.
Insert the collet cone and the trimmer bit into the
offset base, and then tighten the collet nut.
► Fig.33: 1. Trimmer bit 2. Collet nut 3. Collet cone
10. Insert the hex wrench into the hole of the offset
base, and then tighten the collet nut with the wrench.
► Fig.34: 1. Collet nut 2. Wrench 3. Hex wrench
To remove the base, follow the installation procedure in reverse.
NOTE: You can also mount the belt to the pulley with-
out removing the base plate as shown in the figure.
► Fig.35: 1. Pulley 2. Belt
Installing or removing the plunge
base
Optional accessory
1.
Open the lock lever of the plunge base, then insert
the tool into the plunge base all the way aligning the
groove on the tool with the protrusion on the plunge
base.
► Fig.36: 1. Lock lever
2.
Close the lock lever.
To remove the base, follow the installation procedure
in reverse.
Installing or removing the parallel
ruler on the plunge base
Optional accessory
Insert the guide bars into the holes in the plunge base,
and then tighten the wing bolts. To remove the ruler,
follow the installation procedure in reverse.
► Fig.37: 1. Wing bolt 2. Guide bar
Installing or removing the dust
nozzle on the plunge base
Insert the dust nozzle into the plunge base so that the
protrusion on the dust nozzle fits in the notch in the
plunge base, and then tighten the thumb screw on the
dust nozzle. To remove the nozzle, follow the installa-
tion procedure in reverse.
► Fig.38: 1. Protrusion 2. Dust nozzle 3. Thumb
screw
► Fig.39

OPERATION

Using the tool with the trimmer base
Set the tool base on the workpiece without the trimmer bit
making any contact. Turn the tool on and wait until the bit
attains full speed. Move the tool forward over the workpiece
surface. Keep the tool base flush while moving the tool.
When cutting the edge, be sure to keep the workpiece
surface on the left side of the trimmer bit in the feed
direction.
► Fig.40
NOTE: Before cutting on the actual workpiece, it is
recommended to make a sample cut. The proper feed
speed depends on the trimmer bit size, the kind of
workpiece, and depth of cut. Moving the tool forward
too fast may cause a poor quality of cut, or damage
to the bit or motor. Moving the tool forward too slowly
may burn and mar the cutting surface.
When using the trimmer shoe, the straight guide, or the
trimmer guide, be sure to keep it on the right side in the
feed direction. This will help to keep it flush with the side
of the workpiece.
► Fig.41: 1. Trimmer bit 2. Workpiece 3. Straight
guide
17 ENGLISH
