Operation - Maxwell Digital Multimeters 25108 Anleitung

dC current
range resolution
2000μA
20mA
200mA 100μA
5A 10mA
Overload protection
Measuring voltage
fallback
resistance
range resolution
200Ω 100mΩ
2000Ω
20KΩ
200KΩ
2000KΩ
Max. open circuit
voltage
Overload protection
o
peration
Warning
To avoid electric shock and damage to the
device do not measure voltage exceeding 300V!
Always verify the intactness and insulation of
accuracy
1μA
±1.8% +2D
10μA
±2% +2D
±2% +10D
500mA 500V fuse (5A
500V)
200mV
accuracy
±1.0% +10D
1Ω ±1.0% +2D
10Ω ±1.0% +2D
100Ω ±1.0% 2D
1KΩ ±1.0% +2D
3.0V
15 seconds maximum
220V RMS
the measuring wires, connectors and other units
before measuring!
dC and aC voltage measuring
Connect the red measuring wire to the "VΩmA"
•
connector and the black one to the "COM"
connector.
Set the function and range switch to the
•
desired voltage position. If the voltage is
unknown, set the switch to the highest
available range, connect the wires to the
device and the circuit and reduce the range
until the value shown is correct.
dC current measuring
Connect the red measuring wire to the "VΩmA"
•
connector and the black one to the "COM"
connector. (For measuring current between
200mA and 5A connect the red wire into the
"5A" connector).
Set the RANGE switch to the desired DCA
•
position
Open the measured circuit and connect to it
•
serially.
Read the current value from the screen.
•
The "5A" function is designed for limited time
•
use only. The measuring wire should only be
connected to the circuit for the maximum
of 15 seconds and allow a few seconds in
between measurements.
resistance measuring
Connect the red measuring wire to the "VΩmA"
•
connector and the black one to the "COM"
connector.
Set the RANGE switch to the desired OHM
•
position.
Connect the measuring wires to the circuit.
•
Read the resistance value from the screen.
•
diode measuring
Connect the red measuring wire to the "VΩmA"
•
connector and the black one to the "COM"
connector.
Set the RANGE switch to the "
•
Connect the red measuring wire to the anode
•
of the measured diode and the black one to
the cathode.
The opening voltage dropback is shown on
•
EN
User Manual
" position.
