Brief Introduction

Thanks for your purchasing our Lightning 2100 aircraft
from Top RC Hobby, hope this aircraft will bring the
endless joy to you.
★Lightning 2100 is very easy to assemble in several
minutes and the wings are removable, very easy to
carry and maintain.
★Embedded carbon spars and strips in fuselage and
wings, makes the Lightning 2100 with high strength
and make sure of the plane won't be twisted during
the high speed flights.
★ Configured with left wing, right wing and middle
wing, Lightning 2100 can be easily switched to the
smaller size Lightning 1500 if you take out the middle
wing, one model you buy it but enjoy two different
flight experiences.
★ With 10 inch foldable propeller, makes the flight
with a high efficiency and protects it from the damage
of the landing.
Main Specifications
★Wingspan: 2100mm
★Length: 1016mm
★Weight: 1320g
★Thrust: ≥915g
★Flight time: ≥15min
Product Constitution
PNP vers ion
Fuselage, Main wings, Horizontal wing, Connectiong Rod for Horizontal Wings, Connecting rod for Main Wings, accessories bag
Kit with Servos, ESC, Motor, Propeller
★ Very nice appearances with good proportions,
impressing people with a very good visual impact.
★ Very stable flight and flexible performances, easy to
control, can realize the roll and high speed flights.
★ Full-moving tail, very easy to control.
★ With perfect design of the heat dissipation holes on
the body, the motor, ESC and battery could be cooled
fully during the high-speed flying, which makes our
flight very safe.
★ Under the protection of landing skid and spoilers,
Lightning 2100 can land from the ground without any
damages for the foam parts.
★ Unique hidden pushrod design (elevator & rudder
pushrods are hidden in the foams ) makes the model
more simple and nice.
Main configuration
★Motor: C2415-1150KV
★ESC: 40A
★Servo: 9g (plastic gear)*3+9g (metal gear)*1
★R/C System: 2.4GHz 4Ch /optional
★Battery: 3S LiPo 11.1V 2200mAh >25C
� �
