9-channel mode
Channel
CH 1
Master dimmer
CH 2
Strobe effect
CH 3
CH 4
CH 5
CH 6
CH 7
Preset colors
CH 8
Auto and sound
program
CH 9
Speed
Auto- and sound
program
Value Function
000 – 255 Total brightness 0-100 %
000 – 009 No function
010 – 255 Strobe with increasing speed 0-100%
000 – 255 Red, increasing intensity 0 – 100%
000 – 255 Green, increasing intensity 0 – 100%
000 – 255 Blue, increasing intensity 0 – 100%
000 – 255 White, increasing intensity 0 – 100%
000 – 009 No function
010 – 019 Red
020 – 029 Green
030 – 039 Blue
040 – 049 White
050 – 059 Yellow
060 – 069 Magenta
070 – 079 Cyan
080 – 089 Dark orange
090 – 099 Green yellow
100 – 109 Salmon
110 – 119 Turquoise
120 – 129 Light green
130 – 139 Orange
140 – 149 Straw
150 – 159 Lavender
160 – 169 Light blue
170 – 179 Dark blue
180 – 189 Pink
190 – 255 All on
000 – 009 No function
010 – 019 Auto program 1
020 – 029 Auto program 2
030 – 039 Auto program 3
040 – 049 Auto program 4
050 – 059 Auto program 5
060 – 069 Auto program 6
070 – 079 Auto program 7
080 – 089 Auto program 8
090 – 099 Auto program 9
100 – 109 Sound program 1
110 – 119 Sound program 2
120 – 129 Sound program 3
130 – 139 Sound program 4
140 – 149 Sound program 5
150 – 159 Sound program 6
160 – 169 Sound program 7
170 – 179 Sound program 8
180 – 255 Sound program 9
000 – 255 Auto and sound program speed, slow
28/32
> fast
