Knots - Flysurfer Infinity 2.0 Bar Bedienungsanleitung

Loop the steel ring onto the Endline.
42
EN
Flying Lines
Flying lines will also wear over time
and will need to be replaced if they are
very frayed or have damaged sections.
Always replace both Front or Steering
Lines at a time, not only one line.
The Front Lines on the Infinity
2.0 Bar can be easily replaced. Just
remove the old lines by undoing the
larkshead knot. Then attach the new
lines by attaching them between the
steel ring and the guidance-block on
the black line with a larkshead knot.
All manuals and user guides at all-guides.com
To change the Steering Lines you
should first disconnect the leader lines.
Push the floater and stopper ball up.
Open the larkshead knot at
the winder and pull the Leader Line
out of the floater.
Unloop the Steering Line
from the Leader Line.
Loop the new Steering Line
onto the Leader Line.
Thread the Leader Line back through
the floater and reattach it to the knot
on the short line on the winder.
Chickenstick
Remove the old bungie chord
if needed. Thread in a new bungie
through the Quick Release bungie
at the back of the Quick Release
under the black plastic bridge.
With the help of a thin line,
pull both ends of the bungie
through the Chickenstick.
Lightly tension the bungie
and tie a knot on the end.
Check to see if the Chicken-
stick can be pushed through the
loop. Then cut the excess bungie
about 5mm behind the knot and
melt the ends with a lighter.

03.04 Knots

Bowline
The bowline knot is a static loop.
It is used above as well as below
the Adjuster. On the Adjuster the
line for the bowline is doubled.
Make a eye with the line. The
part of the line from where the
pull is coming lies below.
43
EN
