| FUNCTIONS AND DISPLAY

DISPLAY OVERVIEW

Gain
-3 dB
0 dB
+3 dB
+6 dB
Load
10Ω 470Ω
22Ω 1kΩ
47Ω 22kΩ
100Ω 47kΩ
220Ω
DISP
Adjusts the
brightness.
If set to OFF, the
display turns ON
again for a few
seconds when
using the SKC.
EQ Curves
Vinyl records were pressed by different labels: each and every one
could develop and use a different way to record and print records
thus creating different equalisation curves.
Aligning the curves of equalisation of reproduction to match the
curves used to produce the record is the best way to extract the
correct audio signal from the vinyl.
PH-10 offers a variety of the most commonly used curves, starting
with the standard RIAA, followed by the acclaimed original DECCA
LONDON and the AMERICAN COLUMBIA.
Every curve is also offered in its ENHANCED version that can
result in a crisper, more vivid sound extracted from the vinyl and
sometimes useful to achieve even greater dynamic.
Input selection
IN 1
IN 2
6
EN
DE
IT
Type selection
MM
MC
EXT (external)
External power
supply PSU-10
connected.
