| TECHNICAL SPECIFICATIONS

MAIN FEATURES
|
Phono Preamplifier with SKC and TFT
colour display
|
EQ:
3 curves (RIAA, Decca London, American
Columbia) with Enhanced option
|
Subsonic filter:
10Hz/36dB octave
|
Frequency response:
20Hz – 20kHz ± 0.3dB
Enhanced 20Hz – 50kHz ± 0.3dB
|
THD (Total Harmonic Distortion):
<0.05% @ 1kHz
|
Signal to noise ratio:
89dB
|
Dynamic response:
105dB
ANALOGUE INPUTS
|
MM/MC two independent stereo RCA
|
Input sensitivity:
0.1mV MC up to 10.0mV MM
|
Input impedance:
9 options [10Ω, 22Ω, 47Ω, 100Ω, 220Ω,
470Ω, 1000Ω, 22kΩ, 47kΩ]
|
Gain:
MM= 45dB
MC= 65dB
with 4 options [0dB, ± 3dB, + 6dB]
|
MM capacitance:
220pf
AUDIO OUTPUTS
|
Line Outputs level (fixed):
Unbalanced RCA @ 2V and balanced XLR
@ 4V
|
Output Impedance:
50Ω
POWER
|
Power supply:
100-120V or 220-240V, 50/60Hz
|
Power consumption:
10W Super Linear supply
|
Standby consumption:
< 0,5W
|
Fuse 0,5A F/T
DIMENSIONS AND WEIGHT
Dimensions:
200W | 80H | 260D mm
290W | 180H | 390D mm - boxed
Weight:
Kg. 3
Kg. 4 - boxed
