NOTE: If you are
installing the computer
under a desktop or
tabletop, first attach all
cables, and then attach
the stand to the mounting
plate (see "Attaching the
Stand to the Mounting
Plate" on page 19).
NOTE: The power
adapter LED will light
when the adapter is
properly plugged into a
wall outlet and into the
computer.
14
Setup and Quick Reference Guide
All manuals and user guides at all-guides.com

Attaching the Stand

3
Raise the captive screw and slide the chassis stand slat into one of
1
three mounting slots on the back of the computer.
When the stand is in place, tighten the screw.
2
NOTICE: If your computer is oriented under a desktop or tabletop and is in a
high-vibration environment, use the optional wall-mount bracket instead of the
computer stand.

Connecting the AC Adapter

4
Connect the power adapter to the connector on the back of the
1
computer.
Connect the power cable to the power adapter.
2
NOTICE: The following steps apply to Japan only.
