6. Main menu
Antenna setting
Press the right arrow key to switch to the configuration. You can switch back with Exit.
LNB type
LNB voltage
22 KHz
Unicable setting

Toneburst

DiSEqC 1.0
DiSEqC 1.1
DiSEqC 1.2
Hinweis:
In den Antenneneinstellungen müssen Sie in der Regel keine Änderungen vornehmen. Es wird
empfohlen, dass nur erfahrene Benutzer die Einstellungen ändern.
Common Interface
This menu shows all information about the CI module if a suitable module has been inserted. (see
page 22)

Signalinformation

This menu displays information about the currently selected satellite, transponder, signal strength
and signal quality.

6.4 Function

18
Change the LNB type here (default: 09750 / 10600).
Change the LNB voltage supply here (default: On).
Set the 22 KHz setting to on / off (default: Auto)
Select „On" if you want to operate the TV on a Unicable (EN50494).
Select the desired IF channel with the appropriate frequency.
If this does not match your system, you must change it manually.
Choose between None, Burst A, and Burst B
Choose between None, LNB 1 to LNB 4
Choose between None, LNB 1 to LNB 16
Select „On" if you need motor control.
ENGLISH
