Modster Super Cub S2 Bedienungsanleitung Seite 18

User Manual
If the rudder is angled off to the right or
left, adjust the push rod by its arc-shaped
section slightly, making sure the rudder is
properly centered.
Fernsteuerungsanleitung
One-key Aerobatics Button
One-key Return Activation
Throtttle
Ruder
Rudder
Trimmer
One-key Return Switch
18
Push Rod Arc-shaped
Section
P u s h R o d A r c -
shaped
LED Indicator
MODSTER Super Cub S2
If the elevator is angled off to the upper or
lower position, adjust the push rod by its
arc-shaped section slightly, making sure
the elevator is properly centered.
If the aileron is angled off to the upper or
lower position, adjust the push rod by its
arc-shaped section slightly, making sure
the aileron is properly centered.
Push Rod Arc-
shaped
Gyro Switch
Elevator Trimmer
Elevator
Aileron
Aileron Trimmer
ON/OFF Switch
