GB
1. Scope of delivery for Woda-Pure
120 and Woda-Pure Energy
1.
Woda-Pure 120
or
Woda-Pure Energy
Both products have a date ring showing the
next time the filter should be changed.
2. Technical data
Woda-Pure
Filter connection outlet
Diameter Filter connection inlet
Nominal pressure
Flow rate, max.
Flow pressure min.
Nominal flow rate
Service life of the filter, max.
Water temperature, max.
Ambient temperature, max.
Ambient temperature for storage/transport
Overall height A
Distance from ground B
Filter cartridges Ø C
Weight filter cartridge (dry/wet) ca.
Operating position
Production number
* however no longer than 6 months
3. Hazard warnings
The greatest possible equipment safety is one of the
product features at BWT Wassertechnik GmbH that
receives particular attention.
Despite all possible safety precautions, each product
still has inherent risk potential if used incorrectly.
This is why – in the interests of your safety – we have
summarized the "Operation and safety instructions"
below. These should be followed at all times.
10
000_EBA Woda-Pure.indd 10
All manuals and user guides at all-guides.com
JG
mm
kPa/bar
l/h
bar
l/h
Litre
°C
°C
°C
mm
mm
mm
kg
PNR
2.
Installation and operating instructions
3.
Accessories (not included in the delivery)
a. Water tap for installation in the sink
b. Stainless steel gauze hose for connection
to the corner valve (cold water)
3/8"xJG 1/4"
c. Fasteners
120
Energy
1/4" (6,35 mm)
9,65 (for JG connection)
8
200
1
120
10,000*
30
40
-20 to +40
300
200
80
0,5/0,7
vertical
7-812534
7-812535
4. Operation and safety instructions
Qualified personnel
Only trained and authorised persons may install,
operate and maintain filters from BWT Wassertech-
nik GmbH.
Proper use
To get the maximum proper and safe use of filters
by BWT Wassertechnik GmbH, proceed in the ins-
tallation, use and maintenance as described in this
manual.
19.02.2009 10:04:07 Uhr
