OPERATING INSTRUCTION

The following Operating Instructions are used to guide the operation. The step-by-step details are
listed below:
STEP 1 – Check the battery power of the device
The device comes with rechargeable batteries and can be used as received.
If the battery icon is flashing when turned on, it means the battery is running
out of power. Turn off and charge the device with the enclosed USB cable.
The LED light flashes during charging and becomes solid when the device is
charged fully.
Note: When the battery is full, the 3 yellow LED lights are on; when the battery
is running low, only one yellow LED light is on.
STEP 2 - Install the electrode pad onto the device
Snap the enclosed rectangular electrode pad onto the device through the
snap-on connector and use the lead wire to connect the device to the two
square electrode pads. This should be done prior to applying the device onto
the skin of the treatment area.
STEP 3 - Put the electrode pad-installed device on the
stimulation-needed body area
Place the pad-installed device onto the treatment area (such as the bicep).
Press down firmly and ensure a full and firm contact with skin.
Note: The skin should be clean and dry before placing the electrode
pad-installed device.

Battery charging

Electrode pad installation
Place the device on the
body area
EN
17
