Notes on conversion

If a temperature sensor does not emit signals, +888,8 or Sensor line break is
indicated on the controller.
If the EnOcean device offers a presence function, it is regarded as a switch.
Display Briefly press the Press the button for 1
button to 10 s
0 - 6 Increase the chan- Select a channel for the
Permanent nel number by 1 teach-in process
0 - 6 Cancel teach-in Delete taught-in device
Flashing process
A1 - A5 Increase VBus
1 (see page 20)
o0 (not assigned)
Sd
--
Off End energy saving
mode
22
Press the button for
more than 10 s
Delete taught-in device
®
address by
Start update via
MicroSD card
Reset to factory
settings
15

Teach-in devices / Accessories

15.1 FRP12-E wireless room temperature sensor

The FRP12-E measures the room temperature with a
Pt1000 measuring element. The value is transmitted via
radio (EnOcean) and then transferred to the controller
by the VBus ® /EnOcean interface adapter.
• Ideal for retrofitting, no cable has to be laid
• Power supply via an integrated solar cell or optionally
via battery
After the wireless room temperature sensor has been
taught-in, it is available as a temperature sensor input on the controller.
Note:
For more detailed information, see the manual of the wireless room
temperature sensor!

15.2 RTA12-E wireless remote control

The RTA12-E is used for measuring the room tempera-
ture with a Pt1000 measuring element and can additio-
nally be used for comfortably adjusting the heating cur-
ve of the controller from the living area. The values are
transmitted via radio (EnOcean) and then transferred to
the controller by the VBus ® /EnOcean interface adapter.
• Ideal for retrofitting, no cable has to be laid
• Power supply via an integrated solar cell or optionally
via battery
After the wireless remote control has been taught-in, it is available as a tempera-
ture sensor input and remote control on the controller.
Note:
For more detailed information, see the manual of the wireless remote
control!
