Block Diagram PUC2 Line
This block diagram gives a detailed overview of PUC2 Line's internals.
*Note that PUC2 Lite comes with Digital In and Digital Out only.
Analog/
Digital
Converter
Left Right
Analogue Inputs
28
USB
Auto
AES3
Input
Decoder
AES3/SPDIF
Digital In
ZLM
Digital/
Analog
Converter
Left Right
Analogue OutputsD
AES3
Output
Decoder
AES3 Headphone
igital Out AUX Out
