2. Layout (Fig. 1 - 5)

1. Transport handle
2. Quick-coupling
3. Pressure regulator
4. Manometer
5. Safety Valve
6. ON/OFF switch
7. Pressure vessel
8. Wheel
9. Air filter
10. Supporting foot
11. Drain plug for condensation water
a Screw (Supporting foot)
b Nut (Supporting foot)
c Nut (Wheels)
d Spring Washer (Wheels)
e Screw (Wheels)

3. Scope of delivery

m ATTENTION!
The device and packaging materials are not toys! Children must not be allowed to
play with plastic bags, film and small parts! There is a risk of swallowing and suffo-
cation!
• 1x Screw (Supporting foot)
• 1x Nut (Supporting foot)
• 2x Nut (Wheels)
• 2x Spring Washer (Wheels)
• 2x Screw (Wheels)
