Display-Symbole
ICON
(black)
(black)
(black)
(black)
(red)
(red)
(gray)
(blue)
(gray)
(orange)
(blue)
%
(blue)
(black)
(blue)
(red)
(green)
(orange)
Name
Low Alarm set
High Alarm set
Low Alarm set
High Alarm set
Low Alarm triggered
High Alarm triggered
Transmitter ON
Active pairing
(RF) Wireless
(RF) wireless
REL mode
%WME mode
External probe
Internal probe
Recording
Sensor (transmitter)
battery
Analyzer (receiver)
battery
Function
Audible Low Alarm is set and active
Audible High Alarm is set and active
Visual-only Low Alarm is set and active
Visual-only High Alarm is set and active
Low Alarm has been triggered
High Alarm has been triggered
Transmitter is ON but not communicating with
peripheral device via Bluetooth
TM
Active Bluetooth
communication between
receiver and peripheral device
Wireless transmitter is ON; sensor
communication is INACTIVE
Wireless transmitter is ON; sensor
communication is ACTIVE
Reading moisture using non-invasive sensor
Reading moisture using 'pin' sensors
Reading measurement from external probe
Reading measurement from internal probe
Unit is actively recording (on-screen)
Sensor battery (shown here fully charged)
Analyzer battery (shown here minimally
charged)
5
TM
MO270-de-DE_v2.4 8/16
