EN
3. The charger LED lights up
4. If the battery is fully charged, the LED on the charger will turn green. After charging, remove the battery or
the radio with battery from the charger.
COMMUNICATION RANGE
The maximum coverage distance depends on obstacles and is obtained when the radio is used in an open
field. Maximum distance is limited by factors such as trees or buildings. Inside a car or metal construction, the
distance is considerably reduced.
The coverage distance for the PNI PMR R40 Pro is up to 10 km.
TROUBLESHOOTING
The radio does not turn on
• Check if the battery is properly installed and the battery is charged
Cannot communicate with other radios
• First check if you are on the same frequency or if you use the same CTCSS code with the others you want
to communicate with. Be sure not to be out of range.
My voice is intermittently received
• Check that the microphone is not obstructed by anything. If not, take the radio to a specialized repair
center

TECHNICAL SPECIFICATIONS:

Product color
PMR type
Communication distance
Channels
Security codes
Transmission power
Power supply
Number of pins for audio accessories
TOT (Timeout timer)
LED torch
Automatic energy saver
Channel monitoring
Squelch
Scan
Working temperature
Weight
Dimensions
4
Black / Orange
PMR 446 MHz
Up to 10 km
16 channels (8 channels PMR446 + 8 pre-programmed channels)
Yes
0.5 W
Li-Ion battery 3.7V 1200mAh
2 pins (PNI type)
Yes, default 180 sec.
Yes
Yes
Yes
Yes, automatically, default level 5
Yes, on channel 16
-26 ~ + 60 ° C
140 g (battery included)
170 x 55 x 30 mm (antenna included)
