Parts List
Ersatzteileliste
Parts List
En
Parts # Qty Description
15105
1
NITRO STAR G3.0 ENGINE with PULLSTART
3815
2
VINTAGE 5 SPOKE WHEEL 26mm MATTE CHROME 0mm OFFSET
3820
2
VINTAGE 5 SPOKE WHEEL 31mm MATTE CHROME 6mm OFFSET
3837
2
TE37 WHEEL 26mm CHROME (0mm OFFSET)
3838
2
TE37 WHEEL 26mm BRONZE (0mm OFFSET)
4790
2
X-PATTERN RADIAL TIRE 26mm D-COMPOUND
4793
2
VINTAGE RACING TIRE 26mm D-COMPOUND
4797
2
VINTAGE RACING TIRE 31mm D-COMPOUND
50474
1
SILICONE TUBE 2x5x300mm
6122
10
BODY PIN (MEDIUM)
6154
10
NYLON STRAP (3.5x150mm/BLACK)
6163
5
SERVO TAPE 20x100mm
6274
1
PRECUT FOAM BUMPER GRAY (RS4)
6807
2
SHOCK SHAFT 3x31mm
6816
6
SILICONE O-RING S10
6819
5
SILICONE O-RING P-3 (RED)
6836
2
SHOCK SPRINGS 13x29x1.55mm (BLACK)
72001
2
PILOT SHAFT 4x30mm
72102
2
SHOCK CAP 12xM13x0.8mm (PURPLE/ GROOVED)
72107
2
CUP JOINT 5x10x16mm
72108
1
CUP JOINT 5x10x16mm
72140
1
AIR CLEANER 30mm
72144
1
LINKAGE SET
72148
1
BRAKE CAM SHAFT/PLATE SET
72157
1
ARM BRACE SET
72161
1
GEAR SHAFT 5x55mm (NITRO 2 SPEED)
73913
1
MAIN CHASSIS 2.5mm (6065 ALUMINUM/PURPLE)
76817
1
SPUR GEAR 47 TOOTH (1M) (NITRO 2 SPEED)
76822
1
SPUR GEAR 52 TOOTH WITH COLLAR SET (1M)
76843
1
SPUR GEAR 43 TOOTH (1M) (2 SPEED/NITRO 3)
76978
1
ALUMINUM THREADED PINION GEAR 18Tx12mm (1M)
76982
1
ALUMINUM THREADED PINION GEAR 22Tx12mm (1M)
85029
1
RADIO TRAY SET
85030
1
SUSPENSION ARM SET
85031
1
SHOCK TOWER/ BUMPER SET
85032
1
BODY POST/ LINK SET
85033
1
SUPPORT SET
85036
1
GEARBOX SET
85037
1
REAR HUB SET (2 DEGREE/ 1 DEGREE)
85038
1
FRONT UPRIGHT SET (8 DEGREE/ 10 DEGREE)
85039
1
SERVO HORN (FOR SLIDE CARB./NITRO 3/NITRO MT/SUPER NITRO RALLY)
86014
1
GEAR DIFF BEVEL GEARS (13T AND 10T)
86016
1
GEAR DIFF O-RING SET
86021
1
FLYWHEEL (WITH COLLET AND PINS)
86022
1
COLLET 6x10mm
86023
1
CENTER DOGBONE 6x60mm
86036
2
DOGBONE 6x52mm
86037
1
ALUMINUM EXHAUST HEADER (BLACK)
86038
1
2 SPEED TRANSMISSION
86039
1
THREADED 2 SPEED CLUTCH BELL 12mm (NITRO 3 2 SPEED)
86050
1
2 SPEED MAINTENANCE KIT
86329
1
HEAVY-DUTY FINAL GEAR SET (P1x36T/P1x14T)
86907
1
ALUMINUM TUNED PIPE (RIGHT MOUNT)
86910
1
EXHAUST COUPLING
87021
1
FUEL TANK WITH PRIMER (75cc)
87022
3
FOAM TAPE 25x60mm
87023
1
GEAR DIFF ADJUSTMENT SPRING
87028
1
PTFE CLUTCH SHOE AND SPRING SET
87207
1
AIR CLEANER (12-18 SIZE)
93317
2
TURNBUCKLE 4-40x34mm
A249
4
BALL M2x3.8x4.5mm
A280
2
FLANGE SHAFT SET 3x25mm/A284 3x30mm
A281
2
FLANGE SHAFT SET 3x36mm/A282 3x42mm
A396
1
SERVO SAVER SET
A431
1
DIFF CASE
A471
2
SHOCK PARTS SET
A540
2
HPI SPORTS SHOCK BODY (45-56mm)
A556
2
AXLE 5x32mm (FRONT)
A557
2
AXLE 5x38mm (REAR)
A558
2
DIFFERENTIAL SHAFT
A559
1
GEAR SHAFT 5x37mm
A770
2
HPI SPORT SHOCK SET 45-56 SET
A805
1
PILOT SHAFT M5
A838
4
FLANGE PIPE 3x4.5x5.5mm
A855
1
DIFF FINAL GEAR SET (P1x38T/P1x13T)
A875
5
EX GASKET
A880
1
CLUTCH BELL FOR NITRO RS4 2 SPEED
A881
1
CLUTCH HOLDER FOR NITRO RS4 2 SPEED
A882
1
HEAVY-DUTY 1ST GEAR ADAPTER (PURPLE/NITRO 2 SPEED)
A896
1
THROTTLE LINKAGE SET
B021
2
BALL BEARING 5x10x4mm
B022
2
BALL BEARING 5x11x4mm
B030
2
BALL BEARING 10x15x4mm
Z125
14
BALL CUP
Z136
4
BALL END 4-40 (BLACK)
Z150
1
ANTENNA PIPE SET
Z164
1
HEAVY WEIGHT GREASE (#30000/GEAR DIFF)
Z170
1
SILICONE SHOCK OIL #300 (10cc)
Z224
10
WASHER M3x8mm
Z238
4
C CLIP 13mm
Z242
20
E CLIP E2mm
Z251
10
SPRING PIN 1.5x8mm
Z264
10
PIN 2x10mm SILVER
Z282
4
STEP SCREW M3x14mm
Z509
6
BUTTON HEAD SCREW M3x30mm
Z517
10
BINDER HEAD SCREW M3x8mm
Z526
6
FLAT HEAD SCREW M3x8mm
Z527
6
FLAT HEAD SCREW M3x10mm
Z543
6
CAP HEAD SCREW M3x10mm
Z561
6
TP. FLANGED SCREW M3x10mm
Z567
10
TP. BINDER HEAD SCREW M3x10mm
Z568
10
TP. BINDER HEAD SCREW M3x12mm
Z569
10
TP. BINDER HEAD SCREW M3x15mm
Z578
10
TP. FLAT HEAD SCREW M3x12mm
Z581
10
TP. FLAT HEAD SCREW M3x18mm
Z593
4
SCREW SHAFT 3x27mm
Z599
4
SCREW SHAFT 3x40mm
Z653
6
NUT M3
Z662
4
LOCK NUT M2
Z684
4
FLANGED LOCK NUT M4
Z694
10
WASHER M5x10x0.5mm SILVER
Z699
6
WASHER 7x12x0.8mm (BLACK)
Z721
4
SET SCREW M4x4mm
Z903
1
ALLEN WRENCH 2.5mm
Z904
1
ALLEN WRENCH 2.0mm
Z950
1
CROSS WRENCH (SMALL)
Z960
1
TURNBUCKLE WRENCH
Downloaded from
www.Manualslib.com
Liste de pièces
Listado piezas
manuals search engine
Ersatzteilliste
De
Nummer Anzahl Beschreibung
15105
1
NITRO STAR G3.0 MIT SEILZUGSTARTER
3815
2
RETRO 5-SPEICHEN FELGEN 26mm M.-CHROM (0mm OFFSET)
3820
2
RETRO 5-SPEICHEN FELGEN 31mm M.-CHROM (6mm OFFSET)
3837
2
TE37 FELGE 26mm CHROM (0mm OFFSET)
3838
2
TE37 FELGE 26mm (BRONZE/0mm OFFSET)
4790
2
X-PATTERN PROFIL REIFEN 26mm D-COMPOUND
4793
2
RACING REIFEN D-MISCHUNG 26mm RETRO LOOK
4797
2
RACING REIFEN D-MISCHUNG 31mm RETRO LOOK
50474
1
SILIKONSCHLAUCH 2x5x300mm
6122
10
KAROSSERIESPLINTE MITTEL
6154
10
KABELBINDER (3.5x150mm/SCHWARZ)
6163
5
DOPPELSEITIGES KLEBEBAND 20x100mm
6274
1
ANGEPASSTER RAMMER GRAU RS4
6807
2
KOLBENSTANGE 3 x 31mm
6816
6
SILIKON O-RING S10
6819
5
SILIKON O-RING P-3 ROT
6836
2
FEDERN 13x29x1.55mm (SCHWARZ)
72001
2
BOLZEN 4 x 30mm
72102
2
DAEMPFERKAPPE 12xM13x0.8mm (LILA)
72107
2
MITNEHMER 5 x 10 x 16mm
72108
1
MITNEHMER 5 x 10 x 16mm
72140
1
LUFTFILTER 30mm
72144
1
BREMSGESTAENGE
72148
1
BREMSBACKENSTANGE MIT BREMSBACKEN
72157
1
ACHSSTIFTEHALTER
72161
1
GETRIEBEWELLE 5x55mm (2-GANG GETRIEBE)
73913
1
CHASSIS 2.5mm (6065 ALUMINIUM/LILA)
76817
1
HAUPTZAHNRAD 47Z (1M) (NITRO 2 2-GANG)
76822
1
52Z HAUPTZAHNRAD NITRO MT 2-GANG MIT BEILAGSCH.
76843
1
HAUPTZAHNRAD 43Z (1M) (NITRO 3 2-GANG)
76978
1
ALUMINIUM RITZEL MIT GEWINDE 18Z x 12mm (1M)
76982
1
ALUMINIUM RITZEL MIT GEWINDE 22Z x 12mm (1M)
85029
1
RADIOPLATTENSATZ
85030
1
UNTERER QUERLENKERSATZ
85031
1
DAEMPFERBRUECKE / RAMMERSATZ
85032
1
KAROSSERIEHALTER / SPURSTANGENSATZ
85033
1
VERSTREBUNGSSATZ
85036
1
GETRIEBEKASTENSATZ
85037
1
RADTRAEGER HINTEN (2 GRAD / 1 GRAD VORSPUR)
85038
1
LENKHEBELTRAEGERSATZ (8 GRAD / 10 GRAD NACHLAUF)
85039
1
SERVOHORN (FUER SCHIEBEVERG./NITRO 3/NITRO MT/SUPER NITRO RALLY)
86014
1
KEGELDIFF ZAHNRAEDER INKL. STIFT
86016
1
SPRINT KEGELDIFF O-RINGSATZ
86021
1
SCHWUNGSCHEIBE (HUELSENTYP / MIT PINS)
86022
1
SCHWUNGSCHEIBENHUELSE 6x10mm
86023
1
MITTEL-ANTRIEBSKNOCHEN 6x60mm
86036
2
ANTRIEBSKNOCHEN 6x52mm
86037
1
ALUMINIUM KRUEMMER (SCHWARZ)
86038
1
2-GANG GETRIEBE
86039
1
2-GANG KUPPLUNGSGL. MIT GEWINDE (NITRO 3 2-GANG)
86050
1
2-GANG WARTUNGSSATZ
86329
1
EXTRA STABILE ZAHNRAEDER (P1x36Z/P1x14T) N3
86907
1
ALUMINIUM RESO-ROHR (RECHTSMONTAGE/N RS4/MT2)
86910
1
AUSPUFFVERBINDER (FIRESTORM)
87021
1
KRAFTSTOFFTANK (75CCM)
87022
3
SCHAUMSTOFF KLEBEBAND 25x60mm
87023
1
KEGELDIFF EINSTELLFEDER
87028
1
PTFE KUPPLUNGSBACKENSATZ INKL. FEDERN
87207
1
LUFTFILTER (12-18 MOTOREN)
93317
2
SPURSTANGE 4-40x34mm
A249
4
KUGEL M2x3.8x4.5mm
A280
2
ACHSSTIFTSATZ 3x25mm / 3x30mm
A281
2
ACHSSTIFTSATZ 3x36mm / 3x42mm
A396
1
SERVO SAVER SATZ
A431
1
DIFFERENTIALGEHAEUSESATZ
A471
2
DAEMPFERTEILESATZ
A540
2
SPORTS DAEMPFERGEHAEUSE 45-56mm
A556
2
RADACHSE VORNE 5 x 32mm
A557
2
RADACHSE HINTEN 5 x 38mm
A558
2
DIFFERENTIALRADMITNEHMER
A559
1
GETRIEBEWELLE 5x37mm
A770
2
SPORTS DAEMPFERSATZ 45-56mm
A805
1
BOLZEN M5
A838
4
METALLHUELSE 3 x 4.5 x 5.5mm
A855
1
DIFFERENTIAL KEGELRADSATZ P1x38Z/P1x13Z
A875
5
AUSPUFFDICHTUNG
A880
1
KUPPLUNGSGLOCKE FUER NITRO RS4 2-GANG
A881
1
KUPPLUNGSHALTER FUER NITRO RS4 2-GANG
A882
1
ZAHNRADMITNEHMER 1.GANG HD (LILA/NITRO 2-GANG)
A896
1
GASGESTAENGESATZ
B021
2
COMPETITION LOW FRICTION KUGELLAGER 5x10mm
B022
2
COMPETITION LOW FRICTION KUGELLAGER 5x11x4mm
B030
2
COMPETITION LOW FRICTION KUGELLAGER 10x15x4mm
Z125
14
KUGELPFANNEN
Z136
4
KUGELKOPF 4-40 SCHWARZ
Z150
1
ANTENNENROHRSET
Z164
1
ZAEHES FETT (#30000/KEGELDIFF)
Z170
1
SILIKON DAEMPFEROEL #300 (10cc)
Z224
10
UNTERLAGSCHEIBE M3x8mm
Z238
4
C-CLIP 13mm
Z242
20
E-CLIP E2mm SILBER
Z251
10
STIFT 1.5x8mm
Z264
10
STIFT 2x10mm SILBER
Z282
4
STUFENSCHRAUBE M3x14mm
Z509
6
FLACHKOPFSCHRAUBE M3x30mm
Z517
10
FLACHKOPFSCHRAUBE M3x8mm SCHWARZ
Z526
6
SENKKOPFSCHRAUBE M3x8mm
Z527
6
SENKKOPFSCHRAUBE M3x10mm
Z543
6
INBUSSCHRAUBE M3x10 SCHWARZ
Z561
6
SCHNEIDSCHRAUBE MIT FLANSCH M3x10mm
Z567
10
FLACHKOPFSCHNEIDSCHRAUBE M3x10mm
Z568
10
FLACHKOPFSCHNEIDSCHRAUBE M3x12mm
Z569
10
FLACHKOPFSCHNEIDSCHRAUBE M3x15mm
Z578
10
SENKKOPFSCHNEIDSCHRAUBE M3x12mm
Z581
10
SENKKOPFSCHNEIDSCHRAUBE M3x18mm
Z593
4
ACHSSTIFT MIT GEWINDE 3x27mm
Z599
4
ACHSSTIFT MIT GEWINDE 3x40mm
Z653
6
MUTTER M3
Z662
4
STOPPMUTTER M2
Z684
4
STOPPMUTTER M4 MIT FLANSCH
Z694
10
UNTERLAGSCHEIBE M5x10x0.5mm SILBER
Z699
6
UNTERLAGSCHEIBE 7x12x0.8mm (SCHWARZ)
Z721
4
MADENSCHRAUBE M4x4mm
Z903
1
INBUSSCHLUESSEL 2.5mm
Z904
1
INBUSSCHLUESSEL 2.0mm
Z950
1
KREUZSCHLUESSEL KLEIN
Z960
1
SPURSTANGENSCHLUESSEL
