3.1

Dimension drawings

Sinusoidal filter
dimensions
6SE70 _ _ - _ _A _ _ - 1F_0
6SE70 _ _ - _ _B _ _ - 1F_0
6SE70 _ _ - _ _C _ _ - 1F_0
6SE70 _ _ - _ _D _ _ - 1F_0
for M6 bolt
F
SIEMENS
C/L+ D/L-
U1/L1 V1/L2 W1/L3
Studs G
Grounding
U2/T1 V2/T2 W2/T3
studs H
Rating
plate
Warning
label
A
for M6 bolt
SIEMENS AG 6SE7087-6CX87-1FC0
SIMOVERT MASTERDRIVES
A B
90 500
135 500
180 675
270 675
Table 3-3 Dimensions for size A to D
45
Fig. 3-1 Dimension drawing of sinusoidal filters, size A to D
Betriebsanleitung / Operating Instructions
C D E
[mm]
475 425 350
475 425 350
650 600 350
650 600 350
max 150
Air discharge
C/L+ and D/L connections
(for version A)
E
Power connections
Air entry
max 150
Installation and Connection
F G H
Studs
Grounding
studs
−
M6 M6
45 M8 M8
90 M8 M8
90 M8 M8
58
IN
OUT
25
