Operating Manual
Inductive Positioning System BIP AD0-B014-01-EP02
No. 872877 EN E16
Technical data
Working range Sa min.
Working range Sa max.
Linear range Sl min.
Linear range Sl max.
Linearity error max.
Rated operating dist. Se
Repeat accuracy
Ambient temperature Ta min.
Ambient temperature Ta max.
Opt. working temperature min.
Opt. working temperature max.
Adjustment indicator
Power indicator
Electrical data
Eff. operating voltage Ue DC
Operating volt. UB min. DC (Ua)
Operating volt. UB max. DC (Ua)
Ripple max. (% of Ue)
Rated insulation voltage Ui
Rated frequency, AC
Output current at Sl min.
Output current at Sl max.
Output current at Se
Load resistance RL min.
No-load current max. Io at Ue
Short circuit protected
Protected against miswiring
Polarity reversal protected
Mechanical data
Housing material
Tightening torque
Sensing face material
Connection type
Cable jacket material
Cable diameter D max.
Cable short description
Cable Length
Number of conductors
Conductor cross section
Cable Screen
Enclosure Type per IEC 60529
Shock rating
Vibration rating
Degree of contamination
Approvals
4
0
mm
14
mm
0
mm
14
mm
±250
µm
7
mm
±80
µm
-25
°C
+70
°C
10
°C
50
°C
yes
no
24
V
15
V
30
V
10
75
VDC
DC
0
V
10
V
5
V
2.000
Ohm
20
mA
yes
yes
yes
PA
0.5
Nm
PA
Cable
PUR
3.0
mm
Li9Y-11Y-0
2.0
m
3
0.14
mm²
no
IP67
Half-sinus 30gn,11ms
55Hz, 1mm ampl., 3x30min
3
CE
Remarks
The position encoder can be moved in the range
D=0.5mm to 2mm in front of the active surface in the
measurement direction (see installation diagram 1+3).
The resulting non-linearity of the output signal is minimal
in the distance range D=1.0 mm to 1.75 mm. The
technical data, in particular the repeat accuracy, applies
after a warm-up period of 15 min. The position detected
by the sensor (A) lies in the center of the position encoder
(line of symmetry).
Position encoder
BAM TG-XE-001
BAM TG-XE-002
