6.2

Fastening

The rotor spray must be fastened using a clamp holder.
Observe the permissible clamping range while doing so.
Insert an elastomer strip (rubber sheet) to protect the rotor spray from too high clamping
forces or, if applicable, from clamping
WARNING!
The rotor shaft must be treated particularly carefully because even a slight
damage through bending or alike can lead to incorrect speed and thus to
insufficient wetting with product and reduction in the service life of the bearing
NOTICE!
The fastening should be done in such a way that the adjustment ring for speed
adjustment remains accessible as well as it is possible to clean the parts that
came in contact with the product at all times.
