AERMEC VMF-RCC Handbuch Seite 86

Subject Electronic adjustment
E5 panel technical specifications
Document
Edition 1 Date
Using the Page Up and Page Down keys, scroll the pages contained in the sub-menu.
F
AN COIL CONNECTION PAGE
From this page it is possible to carry out the self-addressing procedure of the fan coils installed
in the network. Level: super_user .
PROCEDURE
PROCEDURE STATUS: shows whether the self-addressing procedure is active
NFR: number of fan coils recognised by the VMF-RCC panel.
The increase, decrease and enter keys have no function in this page.
By pressing the ON (
possible to confirm or block the start-up of fan coils self-addressing. If you continue with
acknowledgement of the fan coils network, you go back to the fan coils connection page and the
ON key changes-over to OFF (
procedure that can be traced back to the sequence below:
1. Procedure start
2. Send broadcast control to all fan coils in which the first address is set
3. Wait for confirmation of a fan coil to accept the address (To confirm the address in the
fan coil just change the position at the selector switch of the thermostat functioning
mode)
4. On receipt of confirmation of the acquisition of the new address by a fan coil, increase
the value that indicates the number of fan coils acknowledged and increase the new
address to be set.
5. Send broadcast control to all fan coils in which the new address is set
6. Pass to point 3
2 Fan coil addresses can assume values ranging from 6 to 70.
86 2104_2696105_00
09/08/2017
STATE
) key, pass to the procedure start request screen, from where it is
Author F. Carpanese
). Only by pressing the latter is it possible to block the
Group
Code
Type indoor
NFR
2
