3. Description of the electro-hydraulic pumping unit

3.1 Description of the components

The electro-hydraulic pumping unit consists of the following components:
Table 3
Pos. Description
1 Battery (RAL40/BL1840)
2 battery lock
3 Emergency stop button
4 Compartment
5 Male plug
6 Socket
7 Oil plug
8 Program selection switch Turning knob for the selection of special programs for crimping, cutting, pun-
9 OLED Display
10 LED (red)
11 Forward and return keys
3.2 Brief description of the important features of the unit
The unit is equipped with a special brake which stops the forward motion of the piston/dies when the trigger is re-
leased.
Through an optional USB adapter a report can be generated at the end of a working session at a PC documenting
the proper function of the unit.
HE17600_C © 09/2016
Function
rechargeable 4Ah Li-Ion battery (RAL40/BL1840)
Slide to unlock the battery
To reset the crimping, cutting and punching tools into the starting position in
case of an error.
~ e.g. for remote control and/or carrying belt
Male plug to connect to a female plug on the hose
For remote control, safety foot switch, two hand control and other controls
Oil plug with inspection glass for the hydraulic oil
ching as well as a position to read out data.
High tech organic display to indicate tool and crimping/cutting data
Indicator for Battery charge, Service Intervals and faults
To start/stop the working cycle
Intended Use I.III
