9.2.1 Switching the emergency light mode on and off
Upon delivery, the "Emergency light mode" function is on.
With the function switched off and in case of power failure, the following states
will be activated at the portable lamp.
Before insertion into the charging unit In case of power failure
Main LED and secondary LED - OFF Main LED and secondary LED - OFF
Main LED - ON
Main LED - DIMMED
Main LED - FLASHING
Secondary LED - ON
• Switch the main light on.
• Press button again and keep it pressed.
• With the pushbutton depressed, insert the portable lamp into the charging unit and
keep pressing the button until the LED signals the switchover.
red green green green green Description
9.3

Charging Operation

Danger when used in hazardous areas!
The explosion protection is impaired!
• Use the charging unit in safe areas only.

9.3.1 Battery charging

At room temperature, the charging time of a discharged battery is
approx. 11 hours.
The portable lamp can remain in the charging unit even when the battery is
completely charged.
Charging unit
• Connect to the supply voltage.
• The "Power" LED is lit.
• Insert the portable lamp.
Portable lamp
• Any switched-on LED will be switched off.
• A functional test will be carried out.
• The LED display shows information on the charging state or possible faults.
Upon removal from the charging unit and with the emergency lighting function switched
on
• The LED main light will be switched on.
Upon removal from the charging unit and with the emergency lighting function switched
off
• The function before insertion will be activated.
Main LED - ON
Main LED - ON
Main LED - FLASHING
Secondary LED - ON
Emergency lighting function off
Emergency lighting function on
WARNING
Portable Lamp
SHL 200-Ex
