Ecom SHL 200-Ex Bedienungsanleitung Seite 29

Technical Data
Electrical data
Battery
Service life
Battery
LED
Luminous
characteristics
Lamps
Light intensity
CCT
Light distribution
Functions
Emergency light
duration
Deep discharge
protection
Test function
Lamp control
Battery capacity
Mechanical data
Degree of protection
Enclosure material
Head tilting
Pushbutton
Charge state display
Ambient conditions
Ambient temperature -20 ... +50 °C
Storage temperature -20 ... +50 °C
Charging unit
Version
lead-fleece battery, maintenance-free, 6 V, 4.5 Ah
> 0.5 years at 50 °C
> 4 years at 25 °C
> 50,000 h at 50 °C
main light, LED: 3 W
secondary light, LED: 0.5 W
24,000 cd
6500 K
acc. to DIN 14642
continuous light or flashing light of the main light, continuous light of the
secondary light, function of the main light continuously dimmable
main light: continuous duty:
flashing mode:
secondary light: continuous duty: continuously on, typical 32 h
At a residual capacity of the battery of < 10 %, the main light is automatically
switched to the secondary light.
When the main light is defective, the light is switched automatically to the
secondary light
Determination of the current battery capacity
IP66 (IEC/EN 60529)
Polyamide, impact-strength
toward the front: 100°, toward the back: 90°
main light ON - secondary light ON - main light FLASHING OFF
The LEDs indicate the available capacity for approx. 5 seconds
charging unit LG 200 (for explosion-protected portable lamps)
supply voltage: 110 ... 240 V AC, 50 / 60 Hz and 12 ... 30 V DC
with emergency lighting function and automatic break device for motor vehicle
operation
with power supply cable for 110 ... 240 V AC, 50 / 60 Hz
Optionally, a charging cable for motor vehicle operation for 12 ... 30 V DC
is available.
continuously on, typical 7 h
flashing up to 18 h
Portable Lamp
SHL 200-Ex
Technical data
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
29
