Operating Modes CMx2 DisplayPort
The CMx2 DisplayPort media converter provides two modes of
operation, which can be set via the mode switch.
Transmitter
Switch position
Standard setting „Default"
Manual Operation „Manual"
Receiver
Switch position
Standard setting „Default"
Manual operation „Manual"

Possible Operation Errors CMx2 DisplayPort

Error Possible reasons
LED is off The devices do not get any
power
Green, steady flashing 1.) The module detects an
on the receiver open fiber connection
2.) The fiber optic cable is too
long, or has increased attenua-
tion values
Green, steady flashing HPD (Hot-Plug-Detect) monitor
on the transmitter signal is declared low
LED goes out (2-3 sec.) EDID transmission error
Then flashing on the
receiver
LED goes out (2-3 sec.) EDID transmission error
Then flashing on the
transmitter
Instruction Manual CMx2 Media Converter
CMx2-DisplayPort
CMx2-HDMI
Media Converter
Signal assignment
Minimum DP- Output level (recommended)
Maximum DP-Output level
Signal assignment
Automatic setting
Special settings for EQ / VOD / Pre-
emphasis
Debugging
Überprüfen sie die einwandfreie Funktion der
Netzspannung
1.) Check if the fiber optic cable is plugged
2.) Check the proper function of the fiber optic
cable
1.) The connection from the source to the
monitor is lost. There can be no communication.
Check the DisplayPort cables and the fiber optic
connection
2.) Remove the mains cord, connect all
communication cables and reboot the system
1.) The connection from the source to the
monitor is interrupted. There can be no
communication.
Check the DisplayPort cables and the fiber optic
connection
2.) Remove the power cord connect all
communication cables
1.) The connection from the source to the
monitor is interrupted. There can be no
communication.
Check the DisplayPort cables and the fiber optic
connection
2.) Remove the power cord connect all
communication cables
Notes
