CMx2-DisplayPort
CMx2-HDMI
Media Converter
Technical Data DisplayPort
Color Coding green for DisplayPort 1.2
Resolution: 4K (4096x2160) or UHD (3840x2160) at 60Hz
Uncompressed, color depth 4: 4: 4
Data rate: 21.6Gb / sec, DisplayPort 1.2 connection 20pin male, DPCP compliant, Real EDID (latency = 2 milliseconds)
NO support for DP Dual (HDMI) Mode and FAUX (720Mbps Fast Aux) Mode
2x Gigabit network to Neutrik Ethercon Cat6a (NE8FDX-P6-B)
Internal FiberPort SFP 1310nm / 1550nm 1Fiber GBit Ethernet
Optionally available with Fiberfox EBC1502 or Neutrik OpticalCon® DUO
Operating range at least 300m Multimode 50 / 125μm (OM3)
Implemented power supply 100 - 240V AC, PowerCon® True1 power cord included
Very robust metal housing with M10 thread for truss mounting
19" mounting (frame 18270047) possible, feet can be unscrewed for this purpose
Dimensions (WHD): 143x42x260mm (without feet)
Technical Data HDMI
Color coding blue for HDMI 2.0
Resolution HDMI 2.0 4K (4096x2160) or UHD (3840x2160) at 60Hz
Uncompressed, color depth 4: 4: 4, HDR (High Dynamic Range) capable
Data rate 18Gb / sec, connection HDMI 2.0. (Latency = 2 milliseconds)
DVI Single Link via optional, matching connection cable (not included)
2x Gigabit network to Neutrik Ethercon Cat6a (NE8FDX-P6-B)
Internal fiber port: SFP 1310nm / 1550nm 1fiber GBit Ethernet
Optionally available with Fiberfox EBC1502 or Neutrik OpticalCon® DUO
Operating range at least 300m Multimode 50 / 125μm (OM3)
Implemented power supply 100 - 240V AC, PowerCon® True1 power cord included
Very robust metal housing with M10 thread for truss mounting
19" mounting (frame 18270047) possible, feet can be unscrewed for this purpose
Dimensions (WHD): 143x42x260mm (without feet)
Unpacking
The device left our factory in perfect condition. Please unpack
the individual parts of the delivery carefully. You should find
the following parts:
•
1x Connex CMx2 media converter set (receiver or
transmitter)
•
1x power cable PowerCon® True1 to Schuko
•
1x data cable DisplayPort or HDMI
•
1x operating manual CMx2 media converter
page: 4
Check all parts for completeness and integrity. If damaged, do
not operate the device and inform your dealer.
In the case of shipping damage, inform the transport
company and initiate a damage survey.
Please pay attention to the deadlines required! Without
damage survey a replacement is not possible.
Instruction Manual CMx2 Media Converter
