Kitchen Fit Install (RB33/36 models)

Dimensions

Min 2007 mm
Max 2017 mm
Min 1917 mm
Max 1927 mm
Min: before installed
Max: after installed
Recommended Dimensions for Energy Efficiency
• When the product is installed with cabinet, it is recommended to install refrigerator
with clearance and the holes of cabinet as described above.
• A reduced size of side holes will not restrict the function of appliance but it will
make the refrigerator consume more energy than the rated energy consumption
value.
58 English
DA68-03174R-06.indb 58
Min 595 mm
RB36
RB33
Min 590 mm
50 X 400 mm
Side holes
Min 595 mm
RB36
Min 2017 mm
Max 2027 mm
RB33
Min 1927 mm
Max 1937 mm
50 mm
30 mm
10 mm
200 mm
220 mm
30 mm
Hole
