Preparing the appliance
We recommend that you rinse out the steam generator (15) before using it
for the first time:
• Check that the plug (23) is disconnected from the mains socket.
E • Set the ironing board (1) to its highest position, then remove the water
reservoir (11).
• Place the drain tray (14) beneath the drain cap (22).
G
• First unscrew the steam generator cap (21), then unscrew the drain cap (22).
D
• Remove the small and the large lid (12) from the water reservoir. Remove
MAX
F
the filter compartment with the filter (13).
• Fill the water reservoir with warm tap water up to the MAX level.
D
• Position the large funnel shaped lid (12) at the place of the water reservoir (11)
on top of the steam generator (15) and place the water reservoir above it.
• Once all the water has flown through and the reservoir is empty, screw the
two caps in place again.
• Dispose of the water.
Which water should be used?
Your Laurastar has been designed for use with tap water. It is still
absolutely necessary to use the supplied anti-scale filter (13) in order
to benefit fully and longer from your Laurastar.
MAX
Storing your system
• To turn your appliance off, press the main ON/OFF button (16).
• Remove the power plug (23) and roll the electric cable around the feet of
H the table. If your model has the automatic rewind, pull on the cable in order
to activate the rewind.
• Place the steam hose holder (8) horizontally in the hole designed for this
purpose.
• Place the iron in the iron safety storage box (5). Fold the iron-rest into the
"close" position on top of the table. Hold the table with one hand on the iron
rest side (6). With the other hand grasp the ironing board (1), tilt the table
I
into the vertical position.
• Store your system in a vertical position. You can leave the water in the
reservoir until the next usage.
• NOTE: if you store your system in a horizontal position, you must
empty the water reservoir (11).
E
NOTICE: Never use additives (e.g. per-
fumed water), water containing chemical
products or water from tumble dryers as
these products will have a detrimental
effect on the function of your Laurastar.
H I
- 7 -
A
F
G
LAURASTAR
C
3-5 min.
10 min.
Start up
CAUTION: ALWAYS fill the water reservoir (11) completely
before turning on your Laurastar. Operating the appliance
without water could damage the appliance.
PLEASE NOTE: Operating the appliance without water will
void any limited warranties provided with your appliance.
Installation of the anti-scale cartridge and filling
• Check that the power plug is disconnected from the mains socket.
• Set the ironing board to its highest position.
• Take the water reservoir (11) out. Take off the water reservoir lids.
Install the anti-scale filter (13).
A
• Fill the reservoir with tap water. The filtered water has to reach the
MAX level.
B
• Close the water reservoir with the lids and put the reservoir back on
the steam generator (15).
B
• If the water does not flow, soak the anti-scale filter in cold water for
MAX
3 minutes.
User interface
• ON/OFF = the green indicator light flashes until the appliance is ready
to be used.
ON/OFF
• = Option Laurastar SenSteam. If your appliance is equipped with
the Laurastar SenSteam option (17), the white indicator light signals
that the function is on.
SenSteam
• = Option Pulsed Steam. If your appliance is equipped with the Pulsed
Steam option (18), the white indicator light signals that the function is
LauraStar Auto Steam Picto 01/09/16
Pulse
ON. Fan speed button (19) = choice of four speeds. The white indicator
light signals the intensity chosen.
Fan speed • Empty water light (20) = the red drop shaped indicator light signals that
LauraStar Auto Picto 01/09/16
there is no more water in the reservoir (11).
Water
Switching on your appliance
• Insert the power plug (23) in the socket. If your model is equipped with
the automatic rewinder, first pull the electric cable untill the end-of-cable
mark is visible at the rewinder opening.
• Press the main ON/OFF button (16), the green indicator light will flash
for 3-5 minutes.
C
• When the green indicator light stops flashing and stays on, the appliance
is ready. You can start ironing.
• NOTE: For your comfort and safety, your Laurastar system will
switch off after 10 minutes of non-use.
