Congratulations! You have just purchased a high-quality Laurastar ironing system that combines
Swiss design and technology. Please read this instruction manual and the safety instructions care-
fully before using your appliance for the first time and retain this instruction manual for future use.
Find all our tutorial videos and suggestions on www.laurastar.com
WARNING: Your Laurastar TM product generates heat and steam. Various parts of the
appliance may become very hot during operation and can cause burns.
NOTE : This appliance generates heat and can cause burns. Those parts which get very hot
are marked with this symbol.
Overview and features
1. Ironing board
2. Iron
Steam Hose
3.
4. Special Laurastar cover
Safety storage box
5.
Folding iron-rest
6.
7. Adjustable height handles
Steam hose holder
8.
Steam buttons
9.
10. Vacuum/blower button
Water reservoir
11.
12. Small and large water reservoir lid
13. Filter compartment and anti-scale filter
Drain tray
14.
15. Steam generator
16. Main ON/OFF button with indicator light
Laurastar SenSteam button (option)
17.
18. Pulsed steam button (option)
Fan speed button (4 speeds)
19.
Empty water indicator light
20.
21. Steam generator cap
Drain cap
22.
Power plug and Electric cable
23.
24. Fan
Fan plug
25.
26. Wheels
27. Protective soleplate
Protective soleplate hook
28.
Table of Contents
Safety instructions
Laurastar Smart App
Installation and storage
Start up
Ironing
Filling
Maintenance
Customer service
Problems and solutions
Laurastar App: Q & A
Technical information
Guarantee / Limited Warranty
for the United States and Canada 16
Warning: Failure to comply with this
instruction manual and the safety
instructions may result in serious injury
or damage to property. The manufacturer
accepts no responsibility for such injury
or damage in the event that these safety
instructions are not followed. Keep this
instruction manual for reference by
any and all persons who may use the
appliance.
- 5 -
LAURASTAR SMART APP
1
DOWNLOAD
the Laurastar App
If you have it already, make sure that the App is
up to date.
2
LAUNCH
the App
Launch the Laurastar App and follow the
instructions on your smartphone or tablet.
3
3
CONNECT
6
your smartphone to your Laurastar
6
Insert the power plug of your Laurastar into the wall
8 socket. Activate Bluetooth on your smartphone
or tablet.
9
11
A
12
13
14
15
15
On your Laurastar, push the
button (19), keep it pressed and push the
main ON/OFF button
Release the 2 buttons. All the user interface
LEDs will flash during 20 seconds.
This process can be repeated if the time
available is not sufficient. Once the
connection established, it is not necessary
to reconnect the same smartphone or tablet.
Installation and storage
B
Installing your ironing system
• Remove the appliance from the box and position it vertically on the
ground in a closed position.
• Hold the table with one hand on the iron rest side (6). Hold the middle
of the table (1) with the other hand and pivot it to a horizontal position
(maximum height).
A B
• Unfold the iron-rest to the open position.
• Fit the ironing board cover (4), securing it from the side of the iron rest
to the tip of the ironing board, then adjust. The cover supplied with this
product is specially designed to ensure uniform distribution of air over
the whole board in vacuum or blower mode. Use only a Laurastar
approved cover to ensure that its effectiveness is not impaired. The
cover is washable at 30°C (warm water); do not spin dry.
• Take the iron (2) out of its safety storage box (5) and place it on the
iron-rest (6).
• You can fold the iron-rest into the close position (6a) if you desire.
• Insert the steam hose holder (8) in one of the two holes beside the
C iron-rest (6), fix the steam hose on the steam hose holder (3a). Insert
the protective soleplate hook (28) in the other hole.
• You can lower the table height by clamping the handles (7). There are
six levels. To lift the table, simply pull it up without using the handles.
• To move your Laurastar, simply raise the tip of the board and roll.
- 6 -
