Electrical
connection, page 4
Install the relay with the
connection terminals
facing downwards and
splash-proof. If required
and permitted by legal
Have the driving lamps
set by a specialist garage
Another tip:
• Always keep headlamp
lenses clean. Dirt can
swallow up to 80% of
light power. You drive
safely when you can
see and be seen well.
Do you carry spare
13
regulations, install a
switch on the dashboard.
Disconnect the battery
ground cable (-) for
safety reasons.
Route and connect the
cables according to the
circuit diagram. When
wired according to circuit
or at a service station.
Only correctly set
bulbs and fuses in
your vehicle?
• If you have any
questions or installation
problems: Call Hella
Customer Services:
diagram I the auxiliary
lamps are switched on
together with the existing
driving lamps. According
to circuit diagram II the
auxiliary lamps are switched
in addition to the existing
headlamps via a separate
switch. According to circuit
headlamps ensure
optimum light.
• Outside normal working
hours an answering
machine will record your
inquiries and requests
and Customer Services
will then get back to you.
Ask your dealer for the
complete Hella brochure
or write to:
diagram III the CELIS®
position lamps are
connected and switched
on together with the
parking light. Reconnect
the battery ground cables.
Test the lighting system.
Fasten the supply cables
securely in place.
Hella KGaA
Hueck & Co.
59552
Lippstadt/Germany
