EX-1237HMVS
3. Layout, Connections, LED's & Jumper Settings
3.2 Connections & LED's
7-24V Connector:
USB 3.2 (Gen2) A-Port:
StdB_SSTX +
StdB_SSTX -
VCC
USB 3.2 (Gen2) C-Port:
Note!
By dual assignment of the pins, the USB Type-C plug can be plugged into the port on both
sides.
Status LED's:
Next to each downstream port there is a green LED, which shows you in which mode the port is
working. There are two modes. The following table shows the meaning of the LED signals:
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
ATTENTION!!!
Use only with Power Supply which is included in delivery!
GND_DRAIN
StdB_SSTX+
StdB_SSTX -
GND
D- D+
LED
Off
Steady On USB device is detected and ready
Never plug in with force
or in wrong direction.
Description
No USB device detected
11
English
Attention!
