Luft raum dat ei:
Lufträume werden bei WinPilot in einer Klartext-Beschreibungssprache definiert. Sie können
diese Datei jederzeit an Ihre Bedürfnisse anpassen. Beachten Sie bitte, daß die Datei im reinen
Textformat vorliegen muß, d.h
DOV
GRF 'DWHL JHVSHLFKHUW ZHUGHQ
******* OPEN AIR ™ LANGUAGE *************
•
Version 1.00
•
December 10, 1998
•
Updated October 15, 1999
•
Send comments to
*
*
•
AIRSPACE-related record types:
*
==============================
*
*AC
class
; where class can be:
R
restricted
Q
danger
P
prohibited
A
Class A
B
Class B
C
Class C
D
Class D
GP
glider prohibited
CTR
CTR
W
Wave Window
AN string
;string = Airspace Name
AH string
;string = Airspace Ceiling
AL string
;string = Airspace Floor
AT coordinate
;coordinate = Coordinate of where to place a name label on the map (optional)
NOTE: there can be multiple AT records for a single airspace segment
TERRAIN-related record types (NYI):
TO {string}; Declares Terrain Open Polygon; string = name (optional)
TC
{string); Declares Terrain Closed Polygon; string = name
SP style, width, red, green, blue ; Selects Pen to be used in drawing
PEN STYLES in SP command:
SOLID
DASH
NULL (transparent)
Example: for a 1 pixel wide, dashed, light gray pen use: SP 0,1,192,192,192
SB
red, green, blue ; Selects Brush Color to be used in drawing
Example: to select white interior of a closed polygon, use: SB 255, 255, 255
To select transparent interior use: SB -1,-1,-1
Record types common to both TERRAIN and AIRSPACE
V x=n ; Variable assignment.
Currently the following variables are supported:
D={+|-} sets direction for: DA and DB records
'-' means counterclockwise direction; '+' is the default; D is automatically reset to '+' at the
begining of new airspace segment
X=coordinate
: sets the center for the following records: DA, DB, and DC
Z=number ; makes the element invisible at zoom levels > number
T=1
; transparent Airspace segment (draw border only)
DP coordinate
;add polygon point
DA radius, angleStart angleEnd ; add an arc, angles in degrees, radius in nm
DB coordinate1, coordinate2 ; add an arc, from coordinate1 to coordinate2
DC radius ; draw a circle (center taken from the previous V X record, radius in nm
VLH GDUI 1,&+7 PLW ]% :RUG HGLWLHUW ZHUGHQ XQG GDQQ
Nachfolgend die Dokumentation der Syntax:
jerryp@winpilot.com
0
1
5
(optional)
68
