Setting up an AiMesh WiFi System

Setting up an AiMesh WiFi System
1. Prepare two or more ASUS routers supporting AiMesh.
2. Assign one as AiMesh router, and the other as AiMesh node.
** If you have multiple AiMesh routers, we recommend using the router with
the highest specifications as your AiMesh router and the others as AiMesh
nodes.
3. Go to AiMesh SETUP STEPS.
NOTE: If you set up Ethernet backhaul connection, ensure to connect an
Ethernet cable from the LAN port of the AiMesh router to the WAN port of
the AiMesh node.
10
WAN
LAN2
WPS
AiMesh node
AiMesh Setup Steps
LAN1
LAN3
RESET
DCIN
AiMesh Router
AiMesh router
